automatic stapler

(512) 931-1962
Assembly - Clamps for furniture - automatic stapler

The system is realized by a structure in aluminium profiles with motorized guides with brushless motors for axes X, Y, Z, guaranteeing excellent speed and placements. For the more tilt and rotation axis A and B, was chosen using pneumatic actuators for a good working efficiency, excellent accuracy and reduced mechanical dimensions, ensuring access at every point of the piece of work. This is the best way to get good value for money in the field of automatic stapling systems,compared to expensive anthropomorphic robots, but maintaining similar performance.

Advantages

Easy programmable nailing path, with possibility to clamp and staple more cabinets simultaneously

Labour saving, increased productivity and accuracy

Ability to work in batch-one mode by reading a barcode or job list.

Technical data

Working Area X   2300 mm maximum
Workspace  1300 mm maximum Y
Z maximum work Area  500 mm
Movement allowed in  0° -90° -180° -270°-0.1°
Movement allowed in B  0° -45°-0.1°
Maximum cycle time per cycle of fixing a point  0.7 sec
Minimum positioning accuracy  +/- 0.1 mm
Minimum positioning repeatability  +/- 0.2 mm
Maximum speed of x-axis displacement  1.5 m/sec
Maximum y-axis displacement  1.5 m/sec
